Motherboard MSI PRO B650M-B (PROB650M-B)
ID: 1444
Modification
Product Summary
- Socket: AM5
- Chipset: AMD B650
- Number of memory slots: 2
- Memory type: DDR5
- Expansion slots: PCI-E 40 x16, PCIe 30 x1, PCI-E M2
- Rear panel connectors: USB 2.0, USB 32 Gen1, VGA, HDMI (High-Definition Multimedia Interface)
- Form factor: mATX
Full Specifications
Master
Manufacturer ........................................................................................................................................................................................................
Manufacturer Code ........................................................................................................................................................................................................
PROB650M-B
Socket ........................................................................................................................................................................................................
AM5
Chipset ........................................................................................................................................................................................................
AMD B650
Interfaces
Rear panel connectors ........................................................................................................................................................................................................
USB 2.0, USB 32 Gen1, VGA, HDMI (High-Definition Multimedia Interface)
Audio/Video
Sound ........................................................................................................................................................................................................
8-channel (7.1)
Memory
Memory type ........................................................................................................................................................................................................
DDR5
Number of memory slots ........................................................................................................................................................................................................
2
Learn more
Form factor ........................................................................................................................................................................................................
mATX
Disk controllers
SATA Controller ........................................................................................................................................................................................................
x4 x SATA-III (6 Gb/s)
Supports RAID ........................................................................................................................................................................................................
0, 1, 10
Expansion slots
Expansion slots ........................................................................................................................................................................................................
PCI-E 40 x16, PCIe 30 x1, PCI-E M2
M.2 slot type ........................................................................................................................................................................................................
1x M.2
M.2_1 Source (From CPU) supports up to PCIe 4.0 x4 , supports 2280/2260 devices
Supported PCI Express Modes ........................................................................................................................................................................................................
1x PCI-E x16 slot
• Supports x16 (For Ryzen™ 7000 Series processors)
• Supports x8 (For Ryzen™ 7 8700G and Ryzen™ 5 8600G processors)
• Supports x4 (For Ryzen™ 5 8500G processor)
1x PCI-E x1 slot
PCI_E1 Gen PCIe 4.0 supports up to x16 (From CPU)
PCI_E2 Gen PCIe 3.0 supports up to x1 (From Chipset)
Special Feature
Warranty ........................................................................................................................................................................................................
12/24 months
Manufacturer's website ........................................................................................................................................................................................................
