Power supply CHIEFTEC Core 700w (BBS-700S)

Name: Power supply CHIEFTEC Core 700w (BBS-700S)
Brand: Chieftec
SKU: 325341
Availability: OutOfStock
Rating: 4.6 (75 reviews)

Power supply CHIEFTEC Core 700w (BBS-700S) - photo 2

Power supply CHIEFTEC Core 700w (BBS-700S) - photo 3

Power supply CHIEFTEC Core 700w (BBS-700S) - photo 4

ID: 325341

4.6

Product Summary

Power: 700 W
Standard: ATX12V 23
PFC: active
Fan size: 120 mm
80 PLUS Certificate: Gold

Full Specifications

Out of stock

Specifications

Basic

Manufacturer ........................................................................................................................................................................................................

Chieftec

Manufacturer Code ........................................................................................................................................................................................................

BBS-700S

Power ........................................................................................................................................................................................................

700 W

Standard ........................................................................................................................................................................................................

ATX12V 23

PFC ........................................................................................................................................................................................................

active

Fan size ........................................................................................................................................................................................................

120 mm

Electric current

+3.3V line current ........................................................................................................................................................................................................

22 A

+5V line current ........................................................................................................................................................................................................

22 A

+12V line 1 current ........................................................................................................................................................................................................

58 A

-12V line current ........................................................................................................................................................................................................

0.3 A

+5V Standby line current ........................................................................................................................................................................................................

2.5 A

Learn more

Surge protection ........................................................................................................................................................................................................

yes

Short circuit protection ........................................................................................................................................................................................................

yes

80 PLUS Certificate ........................................................................................................................................................................................................

Gold

Motherboard power cable length ........................................................................................................................................................................................................

65 cm

Connectors

Type of motherboard connector ........................................................................................................................................................................................................

20+4 pin

Number of 4+4-pin CPU connectors ........................................................................................................................................................................................................

Number of 6+2-pin PCI-E connectors ........................................................................................................................................................................................................

Number of 4-pin IDE (Molex) connectors ........................................................................................................................................................................................................

15-pin SATA connector count ........................................................................................................................................................................................................

4-pin Floppy connector count ........................................................................................................................................................................................................

Closing technique

Special Feature

Dimensions (WxHxD) ........................................................................................................................................................................................................

150 x 87 x 140 mm

Warranty ........................................................................................................................................................................................................

12/24 months

Manufacturer's website ........................................................................................................................................................................................................

chieftec.eu

Dear Customers, Please read the product description on the manufacturer's official website before making a purchase. Please check with the online store manager to verify specifications, availability in stock, and price. The manufacturer is at liberty to change the look, composition or specifications without notice.

‌
